1. LED-300/LED-300B adopts 300 high -quality LED light beads of extra-large luminous chips, the brightness is higher, the light spot is more uniform and the service life is longer
2. LED-300/LED-300B adopts the encoder digital dimming and can distinguish the rough dimming and fine dimming modes; therefore, the use is more convenient.
3. A built-in light sensing chip can automatically adjust the brightness of the camera light according to the environmental light intensity.
4. The professional LED driving chip is adopted, the light is stables and the efficiency achieves 93%.
5. Can be mounted on the camera as well as used by a handle.
6. Two color temperature plates are configured and suitable for using under different environments.
Start-up and manual mode
A. Press the power switch and light the LED camera light; rightwards rotate to increase the brightness, or leftwards rotate to reduce the brightness.
B. Switch to fine-adjusting mode through C Fine pushbutton so that the brightness regulation is very fine; the camera light can satisfy your higher adjusting requirement.
M Auto pushbutton is slightly touched, thus the mode is switched to the automatic mode; under the automatic mode, the brightness indication lamp is circularly lighted, the camera light can be automatically adjusted according to the environmental brightness.( Note: under the automatic stata, the brightness cannot be adjusted manually and the camera light cannot be remotely controlled)
Test of electric quantity
Bat push button is slightly touched, electric quantity indication lamps are lighted in order; the displayed quantity is the rest available electric quantity,
“F” light mean “electric Full”
“9,8,7,6,5,4,3,2,1” light mean”electric Quantity”
“*” light mean “electric Empty”
Special application “SOS International Distress Signal”
SOS pushbutton is pressed, thus the functional indication lamp lighted:
“Green” light mean “SOS International Distress Signal”
